The Simplest Way to Get Data from an Arduino into Microsoft Excel PLX-DAQ is really a macro that runs in Microsoft Excel. It is free and can be downloaded from Parallax, Inc. Ironically, it was originally written for Stamp microcontrollers — a competitor to Arduinos; My main concern is data acquisition from arduino + shield into matlab. You can use Arduino serial monitor and copy the data to save in a text file. Besides, you can use a SD card module as a datalogger and save the data both in a. Txt and excel file. Realtime Data Acquisition and Plotting with Arduino and Python Raw. AnalogReadSerial.ino /. AnalogReadSerial: Reads an analog input on pin 0, prints the result to the. So I made a system using Arduino and the amazing 1sheeld to save LDR readings in an Excel sheet and that is what we are going to do now. LDR is an acronym for 'light dependent resistor' as it's a resistance but its value changed with light in the environment. 1Sheeld is a platform for Arduino that allows you to tap into your smartphone's.

Hello everyone and welcome to today's instructable. Acquiring data is one of the crucial part of any project today. Maybe its data from remote satellites or sensor data in a normal closed loop system. Real time data acquisition is a necessity. This acquired data helps in planning the future or avoiding the mistakes done or just for monitoring purpose. The data can be acquired from a physical system either by a wired or a wireless connection.

Today we will see the first one.

Now to acquire the data we need a sensing element that can read the physical parameters and then process and covert that data into digital form. This data will then be sent using the Serial port of the Arduino.

So let's begin the instructable...

Supplies

Step 1: Working of the Project

This project is based on the Arduino Board. The main aim of this project is to collect real time data from the ultrasonic sensor and store it in an excel file. This is called data logging.

The data from the Ultrasonic sensor will be logged into the excel file every time the push button is pressed. The reason of including the push button was to avoid the excess number of values. You can use any other sensor and collect as much as data you want (limit up to an excel column)

Now in order to collect real time data into an excel file we need an application called PLQ-DAQ. This allows arduino to store the data in an excel sheet.

Attachments

Step 2: Gather the Supplies

I would highly recommend you to buy the components from UTSource.net . They provide high quality comonents at affordable rates. And they deliver it at your doorstep on time. They also provide PCB Service at affordable rates. Do check them out.

The modules required to make this project are -

SR-04 Ultrasonic Sensor

Push button

Resistor 10K

Breadboard

Connecting wires

Led (optional)

Step 3: Circuit Diagram

Now let's do the connections.

Connect the push button to digital pin 3.

Attach the Ultrasonic Sensor's Trigger pin to digital pin 9 and the Echo pin to digital pin 10.

Connect a led to digital pin 13 (optional)

Make sure all the connections are done or else you won't get any data in the excel sheet.

Step 4: Uploading the Code to Your Arduino Board

Upload the code I have given below to your Arduino Board.

If you want to get continuous data just remove the if-else statement and the for loop. And you can get continuous data from the sensor into the Excel Sheet.

Step 5: Installing PLX-DAQ

1. Download the PLX DAQ from the link I have given below.

2. After downloading install the plx_daq_install file. (img. 1)

3. After installation you will get a folder with an excel spread sheet. Open it. (img. 2)
